R901307063 DREE6-11/210MG24K24A1M / DREE6-1X/210MG24K24A1M Proportional Pressure Reducing Valve - Product Description

Core Performance & Technical Features

1. High-precision proportional control

   Realize stepless and linear pressure regulation with excellent signal follow-up performance, effectively reducing pressure fluctuation and improving the control accuracy of the entire hydraulic system.

2. Optimized hydraulic structure

   Adopts integrated valve body design with compact size and reasonable internal flow channel, minimizing pressure loss and ensuring high flow efficiency while achieving stable pressure reduction.

3. 24V DC electrical control (24K24A1M)

   Equipped with 24V DC proportional solenoid, it features fast response speed, low power consumption and strong anti-interference ability, easy to connect with various industrial control systems (PLC/CNC) for automatic control.

4. 210MG rated pressure specification

   Supports a rated working pressure of 210MPa, with high pressure bearing capacity and stable performance under long-term high-load operation, adapting to the harsh working conditions of industrial hydraulic equipment.

5. Durable & reliable construction

   Made of high-quality alloy valve body and precision-machined internal spool, with strong wear resistance, corrosion resistance and anti-fatigue performance, effectively extending the service life and reducing maintenance frequency.

Perfect Compatibility & Easy Installation

Wide Industrial Applications

• Construction machinery (excavators, loaders, cranes)

• Metallurgical and mining equipment (smelting furnaces, mining machinery)

• Machine tool equipment (CNC machine tools, forging machines, injection molding machines)

• Industrial automation production lines

• Hydraulic lifting and conveying equipment

• Ship and marine engineering hydraulic systems

Product Advantages

Product Basic Information

• Model No. : R901307063, DREE6-11/210MG24K24A1M, DREE6-1X/210MG24K24A1M

• Product Type : Proportional Pressure Reducing Valve

• Rated Pressure : 210MG

• Electrical Control : 24K24A1M (24V DC)

• Applicable Series : DREE6 Series

• Core Function : Hydraulic system proportional pressure regulation & pressure reduction

We provide professional pre-sales technical consultation and after-sales support for this product. If you have any questions about model matching, system debugging and installation, our professional hydraulic engineers will provide you with one-stop solution suggestions to ensure the perfect matching and efficient operation of the valve in your hydraulic system.

Type Code

01	Sandwich plate	Z
02	Proportional pressure reducing valve	DRE
03	For external analog electronics	no code
	With integrated electronics (OBE)	E
04	Size 6	6
Pressure reduction
05	in channel A (subplate mounting)	no code
	In channel P (sandwich plate valve)	VP
Position of the mating connector (omitted in case of subplate mounting)
06		1
		2
		3
		4
07	Component series 10 ... 19 (10 ... 19: unchanged installation and connection dimensions)	1X
Pressure rating
08	50 bar	50
	100 bar	100
		210
	315 bar	3151)
09	Without check valve	M
Power supply
10	Direct voltage 24 V	G24
11	With manual override	N9
	Without manual override	no code
Electrical connection
12	For type ZDRE:
	Without mating connector; connector DIN EN 175301-803	K4
	For type ZDREE:
	Without mating connector; connector M12	K24
Electrical interface
13	Command value 0 … 10 V	A1
	Command value 4 to 20 mA	F1
	For type ZDRE:	no code
Seal material
14	NBR seals	M
	FKM seals	V
15	Further details in the plain text	*
