Home / Products / Hydraulic Pump / Piston Pump / MSE02/MSE03/MSE05/MSE08 Hydraulic Motor MS18-2-121-A18-1330-00-MR MSE18-2-121-F19-1610-EJ00 Hydraulic Wheel Motor

MSE02/MSE03/MSE05/MSE08 Hydraulic Motor MS18-2-121-A18-1330-00-MR MSE18-2-121-F19-1610-EJ00 Hydraulic Wheel Motor

MSE02/MSE03/MSE05/MSE08 Hydraulic Motor MS18-2-121-A18-1330-00-MR MSE18-2-121-F19-1610-EJ00 Hydraulic Wheel Motor

100% Interchange With Poclain MSE Motor
Warranty: 12 Months just like OEM Motor
Mark: SENHENGYUAN Hydraulics
Short Lead Time, Prompt Delivery

Quantity:
Availability:





Inquire Add to Basket

Product Description

MSE series hydraulic motors are modular products primarily used in engineering machinery, industrial equipment, and other fields. They are characterized by high efficiency, large torque, and a compact structure. Here is a detailed introduction and a comprehensive list of models:

Introduction to MSE Hydraulic Motors

Structural Features: The motor adopts a modular design, integrating components such as torque modules, bearing supports, and oil distribution systems. It is available in both wheel-side motor and shaft motor structures to meet different installation requirements. The inner curve raceway design (including symmetric and asymmetric types) ensures stable torque output and low wear.
Performance Advantages: It has the characteristics of low inertia (e.g., the inertia of the MSE11 model is 0.05 kg.m²), high pressure resistance (the maximum pressure can reach 400 bar), and a wide speed range. The dual-displacement models support variable displacement adjustment, enabling switching between high-speed low-torque and low-speed high-torque modes to adapt to complex working conditions.
Application Fields: Widely used in construction machinery (such as excavators and loaders), agricultural machinery, industrial transmission systems, and other scenarios, it is especially suitable for working conditions requiring high torque and stable operation.
Optional Configurations: Multiple options are available, including fluororubber seals, speed sensors (TD/TR types), reinforced shaft seals, and special paint. Brake configurations and oil port connection types (complying with ISO standards such as ISO 6162 and ISO 9974-1) can also be customized.

Complete List of MSE Models

The MSE series includes multiple sub-series with different displacement specifications. The common models are as follows:

MSE02 Series: MSE02-0 (displacement 213 cm³/tr), MSE02-1 (displacement 235 cm³/tr), MSE02-2 (displacement 255 cm³/tr), MSE02-0 (displacement 332 cm³/tr), MSE02-1 (displacement 364 cm³/tr), MSE02-2 (displacement 398 cm³/tr).
MSE05 Series: It is a modular hydraulic motor, including single-displacement motors (1210 standard size), dual-displacement motors (1210 standard size), Twin-Loc motors (1210 standard size), etc. Specific models can be customized according to displacement, bearing support type, and connection method.
MSE08 Series: Including single-displacement motors (1110 standard size), dual-displacement motors (1110 standard size), Twin-Lock™ motors (1110 standard size), etc. The displacement and installation dimensions can be selected according to actual needs.
MSE11 Series: MSE11-0 (displacement 1048 cm³/tr), MSE11-1 (displacement 1147 cm³/tr), MSE11-2 (displacement 1259 cm³/tr), MSE11-9 (displacement 1263 cm³/tr), MSE11-0 (displacement 1404 cm³/tr), MSE11-1 (displacement 1536 cm³/tr), MSE11-2 (displacement 1687 cm³/tr).
MSE18 Series: It is a modular hydraulic motor, including wheel-side motors and shaft motors. The wheel-side motors cover single-displacement, dual-displacement, and Twin-Lock™ types (1210 standard size), and the shaft motors are available in (2A50) standard size with spline connection options.
