Product Description

A6VE250 Series Variable Plug-In Axial Piston Hydraulic Motor
The A6VE250 series variable plug-in axial piston hydraulic motor is a heavy-duty, high-power solution engineered for the most demanding industrial and mobile hydraulic systems. Spanning models including A6VE250EP1, A6VE250EP2, A6VE250EZ1, A6VE250EZ2, A6VE250HA1, A6VE250HA2, and A6VE250HA2T, this series delivers exceptional torque output and operational stability for heavy-load applications. The specialized model ALA6VE250EZ2/63W2-VZM020B (part number R902403883) is optimized for high-pressure, continuous-operation scenarios, making it a top choice for large-scale machinery.
Core Features
High-Torque Variable Displacement DesignWith a large displacement configuration, the A6VE250 series generates outstanding torque to power heavy-duty equipment, while its variable displacement function allows real-time adjustment of speed and torque to match dynamic workloads. This adaptability maximizes energy efficiency, avoids power waste, and ensures consistent performance even under extreme load conditions.
Plug-In Structure for Easy Installation & MaintenanceThe motor features a robust plug-in design that enables quick mounting and disassembly without complex tools. This structure minimizes equipment downtime during maintenance, replacement, or system upgrades, and its compact footprint simplifies integration into large hydraulic system layouts without sacrificing power output.
Rugged Construction for Extreme EnvironmentsBuilt with high-strength alloy components and precision-machined internal parts, the A6VE250 series offers superior resistance to wear, corrosion, and high system pressures. It performs reliably in harsh working environments such as mining sites, large construction projects, and heavy industrial workshops, extending service life and reducing long-term operational costs.
Stable & Low-Vibration OperationAn optimized internal flow path and advanced piston design reduce hydraulic shock and vibration during operation, resulting in smooth, stable performance with low noise levels. This feature is critical for applications requiring precise motion control, even when handling maximum loads.
Model-Specific Advantages
A6VE250EP1/A6VE250EP2: Equipped with high-precision control valve systems, these models deliver rapid load response and accurate speed regulation, making them ideal for heavy machinery that requires precise positioning, such as large cranes and material handling equipment.
A6VE250EZ1/A6VE250EZ2: Designed with enhanced energy efficiency features, these variants excel in continuous-operation scenarios, reducing power consumption while maintaining high torque output for large excavators and bulldozers.
A6VE250HA1/A6VE250HA2/A6VE250HA2T: Built with advanced heat dissipation technology, these models prevent overheating during prolonged high-load operations, ensuring long-term reliability for mining crushers and industrial presses.
ALA6VE250EZ2/63W2-VZM020B (R902403883): This customized high-pressure model features a specialized valve setup, optimized for extreme working conditions and compatible with large-scale hydraulic systems, delivering unmatched performance and durability.
Typical Applications
The A6VE250 series variable plug-in hydraulic motor is widely used in heavy-industry applications:
Construction machinery (large excavators, bulldozers, crawler cranes, road rollers)
Mining equipment (mining trucks, crushers, drilling rigs, conveyor systems)
Industrial machinery (heavy-duty metal forming presses, large injection molding machines, steel mill equipment)
Marine and offshore equipment (ship deck cranes, offshore drilling platforms)
Whether for extreme heavy-load tasks or continuous high-pressure operations, the A6VE250 series stands as a robust, high-efficiency power core for modern heavy hydraulic systems.

Table of values

Size				28	55	80	107	160	200	250
Series				63	65	65	65	65	65	63
Displacement		V_{g max}	cm³	28.1	54.8	80	107	160	200	250
		V_{g x}	cm³	18	35	51	68	61	76	188
		V_{g min}	cm³	0	0	0	0	0	0	0
Nominal pressure		p_nom	bar	400	400	400	400	400	400	350
Maximum pressure		p_max	bar	450	450	450	450	450	450	400
Maximum speed	at V_{g max}¹⁾	n_nom	rpm	5550	4450	3900	3550	3100	2900	2700
	at V_g< V_{g x}	n_max	rpm	8750	7000	6150	5600	4900	4600	3300
	at V_{g min}	n_{max 0}	rpm	10450	8350	7350	6300	5500	5100	3300
Inlet flow²⁾	at V_{g max} and n_nom	q_{V nom}	l/min	156	244	312	380	496	580	675
Torque	at V_{g max} and p_nom	M	Nm	179	349	509	681	1019	1273	1391
Weight (approx.)		m	kg	16	28	36	46	62	78	110

More models：

R902480869	AA6VE250EP2/63W1-VZM150B
R902476523	AA6VE250EP2/63W2-VZM088B-SO216
R902582577	AA6VE250EP2D/63W1-VZM020BC
R902539394	AA6VE250EP2D/63W1-VZM020BE
R902574098	AA6VE250EP2D/63W1-VZM020HB
R902572086	AA6VE250EP2D/63W1-VZM027FB
R902537486	AA6VE250EP2D/63W1-VZM027FB-SO154
R902573213	AA6VE250EP2D/63W2-VZM020B
R910975544	AA6VE250EZ2/63W2-VZM020B
R902580110	AA6VE250EZ2/63W2-VZM027B
R902431956	AA6VE250EZ2/63W2-VZM027DB-SO179
R902412559	AA6VE250EZ2/63W2-VZM088B-SO144
R902434496	AA6VE250EZ2/63W2-VZM088DB-SO180
R910989642	AA6VE250HA1/63W1-VZM020A
R902415644	AA6VE250HA1/63W1-VZM027A
R902485247	AA6VE250HA1/63W2-VZM020A
R910984718	AA6VE250HA1/63W2-VZM020A
R910990600	AA6VE250HA1/63W2-VZM027A
R902541611	AA6VE250HA1/63W2-VZM027AE
R902420177	AA6VE250HA1T/63W1-VZM027A
R902489507	AA6VE250HA1T/63W1-VZM088A-SO144
R902514041	AA6VE250HA1T/63W1-VZM088A-SO144
R902512184	AA6VE250HA1T/63W1-VZM388A-SO75
R902492752	AA6VE250HA1T/63W2-VZM027A
R902489288	AA6VE250HA1T/63W2-VZM088A-SO144
R902448954	AA6VE250HA2/63W2-VZM027A
R902511374	AA6VE250HA2T/63W1-VZM017A
R902454123	AA6VE250HA2T/63W1-VZM027A
R902468580	AA6VE250HA2T/63W2-VZM020AE
R902477203	AA6VE250HA2T/63W2-VZM020AE
R902479517	AA6VE250HA2T/63W2-VZM027AE
R902406701	AA6VE250HD1/63W1-VZM027BESO98
R910970771	AA6VE250HD1/63W1-VZM027B-SO98
R910983892	AA6VE250HD1/63W1-VZM027B-SO107
R902492188	AA6VE250HD1/63W1-VZM027DB
R902510254	AA6VE250HD1/63W1-VZM027FB
R902512296	AA6VE250HD1/63W1-VZM150B
R902417987	AA6VE250HD1/63W2-VZM020B
R902542261	AA6VE250HD1/63W2-VZM027A
R902461552	AA6VE250HD1D/63W1-VZM088B-SO172
R910974042	AA6VE250HD1D/63W2-VZM020B
R902515239	AA6VE250HD2/63W1-VZM020DB-SO154
R902564456	AA6VE250HD2/63W1-VZM027BE
R902559471	AA6VE250HD2/63W2-VZM020BE
R902539449	AA6VE250HD2D/63W1-VZM010B
R902466597	AA6VE250HD2D/63W2-VZM020B
R902517201	AA6VE250HD2D/63W2-VZM020BE
R902558170	AA6VE250HD2D/63W2-VZM020BE
R902408649	AA6VE250HZ/63W1-VZM020B
R902519832	AA6VE250HZ/63W1-VZM020B-SO101
R902434547	AA6VE250HZ/63W1-VZM027B
R902478242	AA6VE250HZ/63W1-VZM027DB-SO154
R902572924	AA6VE250HZ/63W1-VZM027HB
R902516093	AA6VE250HZ/63W1-VZM088B-SO144
R902451307	AA6VE250HZ/63W1-VZM088B-SO172
R902515201	AA6VE250HZ/63W1-VZM388BESO232
R902513172	AA6VE250HZ/63W1-VZM388B-SO232
R902541154	AA6VE250HZ/63W2-VZM010B
R902470194	AA6VE250HZ/63W2-VZM020A
R902544157	AA6VE250HZ/63W2-VZM027A
R902405140	AA6VE250HZ/63W2-VZM027B
R902406634	AA6VE250HZ/63W2-VZM027BE
R902519834	AA6VE250HZ/63W2-VZM027BE
R902534483	AA6VE250HZ/63W2-VZM027DBESO154
R902512669	AA6VE250HZ/63W2-VZM027DB-SO154
R902571178	AA6VE250HZ/63W2-VZM027FB
R902553727	AA6VE250HZ/63W2-VZM027FBESO275
R902409549	AA6VE250HZ/63W2-VZM088B-SO144
R902423319	AA6VE250HZ/63W2-VZM088B-SO172
R902480236	AA6VE250HZ/63W2-VZM088B-SO172
R902519831	AA6VE250HZ/63W2-VZM088B-SO172
R902465172	AA6VE250HZ/63W2-VZM150B
R902570565	AA6VE250HZ/63W2-VZM388BESO232
R902512291	AA6VE250HZ/63W2-VZM388B-SO232
R902519091	AAA6VE250HA2T/63W1-VSM527FA-SO154
R910999233	AAA6VE250HZ/63W2-VSM017B-SO133
R910969142	AAA6VE250HZ/63W2-VSM089B-SO96
R902431311	AA6VE250EZ2/63W2-VZM027DB-SO154
R902460762	AA6VE250HD1D/63W1-VZM027B
R910988285	AA6VE250HZ/63W1-PZM020B
R910944150	AA6VE250HZ/63W2-PZM020B
R910946611	AA6VE250HZ/63W2-PZM027B
R910994582	AA6VE250HZ/63W2-VZM020B
R910975539	AAA6VE250EZ2/63W2-VZM527B-SO102
R910983642	AAA6VE250HD1/63W2-VZM527B-SO102
R902480867	ALA6VE250EP2/63W1-VZM150B
R902476521	ALA6VE250EP2/63W2-VZM088B-SO216
R902572087	ALA6VE250EP2D/63W1-VZM027FB
R902573212	ALA6VE250EP2D/63W2-VZM020B
R902403883	ALA6VE250EZ2/63W2-VZM020B
R902580109	ALA6VE250EZ2/63W2-VZM027BE
R902519680	ALA6VE250HD1/63W1-VZM027DBE
R902510252	ALA6VE250HD1/63W1-VZM027FBE
R902512294	ALA6VE250HD1/63W1-VZM150B
R902466893	ALA6VE250HD2D/63W2-VZM020B
R902408648	ALA6VE250HZ/63W1-VZM020B
R902543523	ALA6VE250HZ/63W2-VZM027B
R902571175	ALA6VE250HZ/63W2-VZM027FBE
R902409547	ALA6VE250HZ/63W2-VZM088B-SO144
R902423192	ALA6VE250HZ/63W2-VZM088B-SO172
R902512338	ALA6VE250HZ/63W2-VZM388B-SO232
R910990634	ALA6VE250HZ/63W1-PZM020B
R910990636	ALA6VE250HZ/63W2-PZM020B
R902543432	ALAA6VE250HA2T/63W1-VSM527FA-SO154
R910998016	ALAA6VE250HZ/63W2-VSM017B-SO133
R910969154	ALAA6VE250HZ/63W2-VSM089B-SOG
